Fırsat CAT7 4x2x23# F/FTP ( 320 metre ) DIŞ ORTAM DATA KABLOSU

0.0 - 0 Yorum var.

Ürün Kodu : H07-00445-DP7 (C58)
Marka : HCS

Detay CAT7 4x2x23# F/FTP ( 320 metre ) DIŞ ORTAM DATA KABLOSU ÇİFT KILIFLI (( İÇ KILIF LOSH KIRMIZI )) + (( DIŞ KILIF PE SİYAH ))

Stokta Yok!

*
Kdv Dahil

1,48 USD
Toplam Tutar
Fiyatı

40,64 TL+ KDV
Fiyatı

1,25 USD + KDV

Category 7 F/FTP outdoor double-jacketed cable, conforming to IEC 61156-5 and ISO/IEC 11801. The cable contains 4 individually foil-shielded
twisted pairs cabled together, overall shielded with aluminum foil and overall jacketed with a gray LS0H compound for indoor use. An additional
black PE jacket renders the cable suitable for mild outdoor use. The cable fully supports all IEEE 802.3 PoE applications including Type 1, 2, 3 & 4.

BasicConductor:
Solid 23AWG (UL444), bare annealed copper.

Insulation:
SFS-PO.

Total number of insulated conductors:
8, twisted in 4 pairs.

Color code:
Blue x White, Orange x White, Green x White, Brown x White.

Individual pair shield:
Aluminum foil, providing 100% coverage, foil face out.

Drain wire:
Solid, tin-coated copper wire.

Overall shield:
Aluminum foil, providing 100% coverage, foil face in.

Rip cord:
PET rope laid in parallel for easy jacket removal.

Inner jacket:
Low-smoke, Zero-halogen, Flame-retardant compound for indoor use.

Inner jacket thickness:
0.5 mm nom.

Color Red:
RAL 3000.

Inner Diameter:
7.1 mm nom.

Outer jacket:
UV resistant PE compound for outdoor use.

Outer jacket thickness:
1.0 mm nom.

Color Black:
RAL 9005.

Overall Diameter:
9.2 mm nom.

Surface Marking (White):
HCS H07-00445 4x2x23# F/FTP CATEGORY 7 DataLink 600 SHIELDED DJ OUTDOOR CABLE
VERIFIED to IEC 61156-5 & ISO/IEC 11801 CE 2011/65/EU (RoHS-2) [Meter Mark] METER [Batch Number]
